ZEB is built for the most extreme terrain—steep double-black runs, freeride features, and even the pedal back up if that’s in the cards. The all-new LinearXL air spring delivers a coil-like ride—supple off the top, supportive through the mid-stroke, and backed by a fixed bottom-out system for confident end-stroke control—giving you unwavering consistency and predictability. The Delta RC damper features an intuitive Compression adjustor, making setup fast, understandable, and easy to communicate. ZEB delivers the composure riders need to confidently pick their line and hold it—no matter how extreme the trail.
NEW LinearXL air spring delivers a consistent and predictable ride feel backed by afixed bottom-out system for end-stroke control
NEW Delta RC damper with easy-to adjust Compression and independent Rebound features intuitive controls and virtually silent performance, keeping riders focused on the trail
NEW Integrated short fender mount (ZEB Integrated Fender sold separately)
Low-grab SKF wiper seals deliver long-lasting fork performance and a smoother ride
Maxima 920 blended 15w reduces overall fork friction
| Specifications | |
|
Wheel size
|
27.5", 29" |
| Travel (mm) | 150mm, 160mm, 170mm, 180mm |
| Damper Type | Delta RC |
| Fork offset | 38mm (27.5"), 44mm (27.5"), 44mm (29") |
| Color (FS) | Diffusion Black, Gloss Black |
| E-Bike Approved | E-bike Approved, E-bike Approved w/E-MTB Decal |
| Steerer | 1.5" Tapered, 1.8" Tapered |
| Axle | 15x110mm BOOST™ TC Compt |
| Upper tube type | 38mm aluminum |
| Damper adjust | Crown |
| Volume reducer | 0/3 Tokens, 0/4 Tokens, 1/4 Tokens, 1/5 Tokens |
| Spring | Linear XL |
| Max Tire Width (mm) | 74.5 |
| Maximum Rotor Size | 220mm |
| Minimum Rotor Size | 200mm |
| Fender Compatibility | Bolt On - Short (Use AC-FEN-EDRO-A1) |
| Bottom Out | n/a |
| Compression tune | n/a |
| Rebound tune | n/a |
